Planetary Concrete Mixer

Planetary Concrete Mixer

CMP Series Planetary Mixers are manufactured basing on German mixing technology. Capacity range from 50 liters to 4500 liters per batch. It's widely used for mixing precast concrete, dry hard concrete, fiber concrete, ultra high performance concrete, refractory material, ceramics, glass and chemicals.

0.00
0.00


CMP Series Planetary Mixers are manufactured basing on German mixing technology. Capacity range from 50 liters to 4500 liters per batch. It's widely used for mixing precast concrete, dry hard concrete, fiber concrete, ultra high performance concrete, refractory material, ceramics, glass and chemicals.

Item CMP50 CMP100 CMP150 CMP250 CMP330
Out capacity(L) 50 100 150 250 330
Input capacity(L) 75 150 225 375 500
Out mass(kg) 120 240 360 600 800
Mixing power(kw) 3 5.5 7.5 11 15
Discharging power(kw) 3 3 3 3 3
Planetary/Blade 1/2 1/2 1/2 1/2 1/2
Side scraper 1 1 1 1 1
Discharging paddle 1 1 1 1 1
Weight(kg) 700 1300 1450 1600 1700
Dimensions(LXWXH)mm

950*786 *1200

1664*1453*1447

1664*1453*1617

1856*1648*1772

1862*1850*1870
