Chongfa NTAA855-C360S10 engine is equipped with exhaust gas turbocharger, featuring strong power and high efficiency and energy-saving, and can work normally even in the highlands as high as 3,600m. Depending on the customers’ demands, the option Cummins and Weichai engines are available.
The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission capacity and efficiency and high productivity.
Chongfa NTAA855-C360S10 engine is equipped with exhaust gas turbocharger, featuring strong power and high efficiency and energy-saving, and can work normally even in the highlands as high as 3,600m. Depending on the customers’ demands, the option Cummins and Weichai engines are available.
The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission capacity and efficiency and high productivity.
Items |
Specifications |
L × W× H (excluding ripper)(mm) |
8560×4130×3640 |
Engine model |
NTA885-C360S10 |
Ground pressure(Mpa) |
0.105 |
Blade capacity(m3) |
10 Straight tilting blade |
Operating weight(t)(excluding ripper) |
37.2 |
Net power/rated speed (kW/rpm) |
235/2000 |
Blade type |
Straight,Angle,Semi U-blade |
